Harlem Baden Sanitary Relief Phase 4 (11797)
About the Project
Why is this project being designed?
This area currently utilizes a “combined sewer system” in which one pipe in the street carries both stormwater from street inlets and wastewater from homes and businesses. As part of their evaluation, our team of engineers determined that the combined sewer was undersized and in need of repairs. During heavy rains, the combined sewer has been unable to handle the excess water, leading to sewer backups in homes and buildings.
What is the goal of this project?
To fix the problem described above, MSD Project Clear is investing $6.5 million to add a second pipe in the street to manage the stormwater, while the existing pipe will remain dedicated as a wastewater sewer.
- Construction is estimated to begin in the Summer of 2022
- MSD Project Clear will construct 7,987 feet of storm sewer to separate stormwater from the current combined sewer (a sewer that handles both wastewater and stormwater)
- MSD’s contractor will put the pipe in by digging through the surface, a process known as “open-cut.”
What can residents expect?
Though construction for this project is not estimated to begin until the Summer of 2022, it is important to be prepared for what to expect. MSD is currently in the process of contacting property owners to obtain necessary easements for properties MSD will need access to in order to construct the project.
During construction, MSD’s contractor will put the pipe in by digging through the surface, a process known as “open-cut.” Because much of the construction takes place in the roadway, customers may experience lane and road closures. However, MSD will have a traffic mitigation plan to ensure residents have access to homes and businesses, and at least one lane of traffic will remain open at all times.
With any type of construction, residents can expect to see and hear heavy equipment during the sewer excavation process. The pictures above depict what a neighborhood will look like before, during, and after a typical project.
After the contractor installs all new pipes, they will restore the construction site according to all local and District requirements. This could include sodding any disturbed areas, replacing disturbed pavement, reinstalling fences, etc.
At least one MSD Inspector will be on-site part of the day for every day the contractor is working.
What is the timeline?
This is the current tentative project schedule. This is subject to change based on a variety of factors, including weather.
- Design phase completion: Fall 2020
- Easement acquisition completion: Fall 2021
- Estimated construction start date: Summer 2022*
- Estimated construction duration: 19 months
*Anticipated construction start date is subject to change. MSD will notify residents before beginning construction.
During active construction, some property owners may experience driveway access restrictions for a short period of time. The contractor will notify property owners in advance of any temporary access restrictions to allow them time to move their vehicles. The contractor will also fill trenches with gravel or place steel plates over trenches during non-working hours so property owners can use their driveways during those times.
This is a major construction project that will include jackhammering and pavement breaking. MSD and its contractor will follow all local ordinances, however, during work hours, community members should expect regular sounds associated with heavy construction.
During the time that MSD’s contractor is disconnecting a property’s lateral from the current sewer pipe and reconnecting it to the new pipe, they may ask customers to limit water use. In general, this process can take between two to five hours, depending on the complexity of the connection. The contractor will notify property owners in advance.
MSD does not anticipate any other utility interruptions, however, as this is a major construction project, unforeseen disruptions are possible. If this occurs, MSD will coordinate with the utility to inform affected customers and to return utility service as quickly as possible.
After MSD awards a contractor to construct the project, the project team will reach out to community members to introduce them to the contractor and MSD’s construction management team. MSD will send a letter to all properties in the project area with contact information. Additionally, contact information for the construction team will be added to the project page on the MSD website.
Further, during construction, MSD will have an inspector on-site every day during active construction. Community members are encouraged to bring their questions to the on-site inspector or any other member of the project team.
MSD will update Frequently Asked Questions as the project manager receives questions.
- October 21, 2020, Public Meeting Presentation
- October 21, 2020, Public Meeting Notification Letter
- Project Brochure (design phase)
- Preliminary project plans (60% complete)*
- Project area map
- Historical complaints map
*The above preliminary project plans are subject to change as MSD’s engineers and consultants are still finalizing plans.
Ema Stendback, MSD Project Manager
Stephen Hilderbrand, P.E., CDG Engineers, Inc.
(Please mention the Project Number: 11797)
